Touch Screen Digital Low Load Brinell Hardness Tester SHB-62.5 Close Loop Control

Product Categories

Dongguan Quality Control Technology Co., Ltd.

Contact Now

Name: Touch Screen Digital Low Load Brinell Hardness Tester SHB625 Close Loop Control
Brand: iqualitrol
Price: 1 USD

Brand Name : iqualitrol

Model Number : SHB-62.5

MOQ : 1 Set

Payment Terms : T/T

Supply Ability : 20 Sets per Month

Delivery Time : 10 Working Days

Packaging Details : Plywood Box

Control : Close loop Control, sensor loading

Height : Max Specimen Height 200mm

Throat : 130mm

Magnification : 50X, 100X

Visual Measuring : CCD image processing system or video measuring device

database function : can save more than 2000 data

Contact Now

Close loop Control Touch Screen Digital Low Load Brinell Hardness Tester

Technical Specifications:

Model	SHB-62.5
Range of Measurement	5-650HBW
Test Force	9.807, 24.52, 49.03, 61.29, 98.07, 153.2, 294.2, 31.125, 612.9N (1, 2.5, 5, 6.25, 10, 15.625, 30, 31.25, 62.5kgf)
Maximum Height of Specimen	200mm
Distance between Indenter Center and Wall	130mm
Objective	5X, 10X
Total magnification	50X, 100X
Hardness Resolution	0.1HBW
Power Supply	AC 220V,50Hz
Dimension	600330700mm
Weight	75kg

Product Tags:

Close Loop Control Brinell Hardness Tester
